Item No Cable Capacity(Port) Splice Capacity(Core)

SW-3162A-24C 2P Entry,2P Exit 24 Cores

SW-3162A-48C 2P Entry, 2P Exit 48 Cores

• The Core Capacity Of Each Splice tray is 12 Cores

• When Order,Please Marks The Capacity Of F/O Case: 24 OR 48 Cores

• Plastic Material: PC

• Environment Temperature: -40”C~+65”C

• Mechanical Performance Comply With IEC10113-1 Standards

• The splice Case and Sealing Packing Can be Opened and refused More than 10 Times

• Using Life > 30Years

• Size: 410(L)x180(D)x80(H)mm
